Roomute2 Series BedHead Units

Roomute2 Series BedHead Units

Acmd’s bed head unit with rail system is mainly used ICU, NICU, PACU, Special Procedure, LDR post-partum, Transitional step-down, Patient rooms, Emergency departments, Radiology. Quite convenient for managing bedside equipment like monitor, ventilator, IV pump, gas outlet, electrical socket, nurse call extension and other facilities accessories. This bed head consoles enable you set up a “life-island “that allows an integration of functions for monitoring, infusion and breathing.

  • Features
  • Specifications
  • Gallery
  • Related Products
  • Video


Beautiful Appearance

  • Powder coated panels, white color for standard

  • Anticathode oxidation and Surface spray treated. elegant appearance, easy to clean

High Quality

  • Made of Hospital grade 6063-T5 lightweight extruded aluminum alloy, strength with light weight

  • Gas outlets are 10000 times tested

  • Medical grade electric sockets 15 or 20 amp

  • Single Rail weight loading capacity 25kg

Safety and Reliable

  • Separation of electricity and gas. Individual connection of gas outlets and electrical wiring

  • Equipped with fire resistant box for electrical sockets

  • Equipped with nurse call extension, convenient to call nurses

Easy Installation and Maintenance

  • Removable front panel for easy access of gas outlets and electrical sockets

  • Surface mounted gas outlets allow annual maintenance


  • 3 Years


Technical Details

  • Equipped with Medical gas outlets, Electric sockets, Nurse call system, LED lights, Earth outlets, Monitor holder, IV pole

  • Gas outlets optional: DIN, BS, FS, JIS, OHMEDA, DISS, Chemetron

  • Electric sockets: Universal, German, British, French, American standard etc.

  • Fully customized configurations and length to meet hospital’s specific requirements

  • Length optional: 1meter, 1.2m, 1.5m, 2m…customized according to request

  • Panel inside is 3mm thickness.


  • Product Size: 1000mmL*300mmH*110mmT

  • Packing size: 1060mmL*330mmH*150mmT( 1pcs to 1 carton box )

  • Weight: G.W: 8KG; N.W: 7.5KG


  • Frame: Hospital grade 6063-T5 lightweight extruded aluminum alloy

  • Ending cover: Injection molded ABS Fire Retardant Plastic or Aluminum Cover

  • Front panels, top and bottom cover panels removable to provide access for easy installation and maintenance of the services

Electrical Wiring

  • Providing connecting electrical wiring for electric sockets and lights for easy installation service

  • Wiring with heat resistant thermoplastic insulation for hot and neutral


  • Powder coated panels for beautiful appearance and long life time

  • Different pictures optional for children’s room

  • Customized colors with color code

Ordering Information

  • A-BHU36-MUTE1-3OH-4A

  • 36" Means the length of bed head unit ( 24",36",48",60" optional fully customized )

  • "3OH" Means 3 Ohmeda gas outlets

  • "4A" Means 4 American standard electric sockets
