Identify gases using the USA color standard

360°Swivel Inlet Pipe for easy installation,safety system for Non-crossing of Gases

Gas types include oxygen, vacuum, air, nitrogen, carbon dioxide, exhaust gas, etc.

Universal Rough-In Assembly to accept Quick Disconnects

100% air tightness test , leak tested and hydrostatically

10,000 times of plugging and unplugging

Complies with NFPA 99 and CGA G-4.1 standards DIMENSIONS units in inch (millimeter)

Long Copper Tube or threaded interface

Console type, Wall mounted type etc.

Secondary insertion and removal to prevent unintentional pull-out and personal safety

Cover with detachable protection

Packing Size: 460mm*360mm*220mm (Console type)( 22pcs 1 Carton )

Weight: G.W: 11KG; N.W: 10KG (Console type)

Outlet panel: Zinc Alloy

Valve part: Brass

Gas pipe: Copper

Installing bracket: Stainless steel

Gas adapter: Stainless steel

Panel: Aluminum

A-CON-DS-OXY

CON=Installation Type (CON: Console, CONW: Wall mounted)

DS= DISS

OXY=Gas Type(AIR: Medical Air, N20: Nitrogen, CO2: Carbon Dioxide)

( Example:A-CON-DS-OXY :Metal panel type console DISS oxygen gas outlets.)
